Portable Transformer On‑Load Tap‑Changer Tester For Measuring Transition Resistance & Transition Time

The MYK-I On-Load Tap Changer Parameter Tester is a specialized instrument designed for comprehensive analysis of transformer on-load tap changers. As the only moving part connected to the transformer circuit, proper testing of on-load tap changers is essential for transformer maintenance and reliability.This equipment meets the requirements specified in "Procedures for Handling and Preventive Tests for Electrical Equipment" for checking action sequences and switching times of on-load tap changers.

Product Alias

Transformer On‑Load Switch Tester / Tap‑Changer Analyzer / Transformer Tap‑Changer Detector / On‑Load Tap‑Changer Test Set / OLTC Tester / Tap‑Changer Transition Characteristic Tester / Transformer Tap‑Changer Waveform Analyzer / On‑Load Tap Changer Performance Test Instrument

Features

1.The instrument has large output current and its weight is light;
2.Two-stage current output, wider test range and higher stability;
3.Can automatically calculate the transition resistance value and transition time;
4.It has perfect protection circuit and strong reliability;
5.5.7-inch large LCD display, it's easy for on-site operation;
6.U disk storage function, can store more waveforms data .
7.The keyboard and one-button shuttle are operated independently, which makes the instrument more convenient to operate.

Application Scenarios
