Portable DC Winding Resistance Tester With 0.5% Accuracy Four Wire Measurement
| Place of Origin | China Mainland |
|---|---|
| Brand Name | MINGYANG |
| Model Number | MYR10D |
| Minimum Order Quantity | 1 |
| Price | 850usd |
| Packaging Details | carton |
| Delivery Time | 1 week |
| Payment Terms | L/C,D/A,D/P,T/T,Western Union |
| Supply Ability | 1000pcs/month |
Product Details
| Measuring Range | 1-1999μΩ | Accuracy Class | 0.5% |
|---|---|---|---|
| Operating Temperature | -10℃~40℃ | Time Resolution | 1s |
| Current Resolutio | 1μΩ | Place Of Origin | Hubei, China |
| Resolution | 1μΩ | Measurement Accuracy | 0.5% |
| Measurement Range | 1-1999μΩ | Working Power Supply | AC220V ± 10%, 50Hz ± 1Hz |
| Weight | 12kg | Display Mode | Three-and-a-half-digit LCD |
| Volume | 380*350*260 Mm | Product Name | DC Resistance Tester |
| Test Current | <20mA,40mA,200mA,1A,5A,10A | Smaller Resolution | 0.1μΩ |
| Data Storage | 1000 Groups | Working Temperature | -10℃-40℃ |
| Working Humidity | <90%RH | Voltage | AC220V±10% |
| Frequency | 50Hz±1Hz | Battery Parameters | 25.2V/5.2AH |
| Highlight | portable dc winding resistance tester,portable dc resistance tester,winding dc resistance tester |
||
Product Description
Winding Resistance Tester - DC Resistance Tester Portable Transformer Winding Resistance Test Equipment 50A Digital Testing Meter
Product Highlights
-
Advanced Four-Wire Measurement
Measurement accuracy up to 0.05% with resolution as low as 0.1μΩ, ensuring accurate and reliable data for various test scenarios
-
Multi-Range Current Output
Covers a wide current range from 10mA to 10A with multi-gear adjustable output, perfectly adapting to DC resistance tests of transformers, motors, inductors and other electrical equipment of different specifications
-
Strong Anti-Interference Capacity
Equipped with frequency conversion anti-interference technology, it can effectively resist on-site electromagnetic interference and maintain stable operation even in harsh industrial environments
-
Intelligent & Efficient Operation
Features automatic range selection, one-key testing, data cloud storage & analysis functions, which greatly shortens test time and improves work efficiency
-
Comprehensive Safety Protection
Has over-current, over-voltage and discharge alarm protection functions to ensure the safety of operators and test equipment during the testing process
